IAW4.xx IMMO OFF Tool v1.2 – VAG Magneti Marelli IAW ECUs

IAW4.xx IMMO OFF Tool v1.2 is a lightweight, file-based immobilizer OFF utility designed specifically for Magneti Marelli IAW engine control units used in VAG vehicles (Volkswagen Group).
The application works directly on ECU dumps and provides model-specific IMMO OFF handling through a simple dropdown interface.

This tool is intended for professional ECU repair, replacement, and recovery scenarios where immobilizer data must be disabled due to ECU damage, EEPROM corruption, or key/cluster mismatch.

Can be used on many devices as you like, no limits, no online! Free remote installation if needed but it is very simple installation and instructions are in download link when purchased.

Supported IAW ECU families (as shown in the application)

The tool supports the following Magneti Marelli IAW ECU variants, selectable from the built-in dropdown menu:

• IAW 4LV / 4ML

• IAW 4HV / 4TV

• IAW 4AV / 4CV
  (IMMO handled via diagnostic line – pin 19)

• IAW 4MV

The application automatically adapts its IMMO OFF logic based on the selected ECU family.

How the tool works (application logic)

• Load an ECU dump file using Load from File

• Select the correct IAW ECU type from the dropdown list

• The program checks immobilizer status

• If IMMO is detected as ON, the tool disables immobilizer data

• A new modified file is generated and saved separately (original file remains untouched)

No flashing or ECU communication is performed by the software itself — it works purely on dump files.

EEPROM & IMMO handling details

Depending on the ECU type, immobilizer handling differs:

IAW 4LV

• VIN number is displayed inside the program

• PIN code is shown

• No physical IMMO line cut required

IAW 4AV / 4CV / 4HV / 4TV

• Immobilizer is linked to pin 19 (IMMO / diagnostic line)

• Recommended options:

  • Cut IMMO line from pin 19

  • Connect diagnostic line to OBD pin 7

  • OR apply EEPROM write protection

This behavior is clearly indicated inside the application itself, matching real-world ECU wiring logic.

Typical compatible ECUs

The tool is intended for IAW4.xx ECUs commonly found in older VAG petrol vehicles, including:

• VW Polo / Golf (older generations)

• Seat Ibiza / Cordoba

• Škoda Fabia

• Other VAG platforms using Magneti Marelli IAW 4-series ECUs

(Exact ECU compatibility depends on software version and EEPROM layout — always verify ECU label before use.)

Video Demonstration on minute 4:30 bellow

Key features

• Dedicated IAW4.xx IMMO OFF solution

• Simple, fast, offline file processing

• ECU-family-specific logic

• VIN & PIN display for supported ECUs

• Generates safe, modified output file

• No internet connection required

• Ideal for bench work and EEPROM programming

Intended use & legal notice

This software is intended only for lawful purposes, such as:

• ECU repair or replacement

• Immobilizer data recovery

• Authorized vehicle servicing

Use only on vehicles you own or have explicit permission to service.
The seller assumes no responsibility for misuse.
